OptiSpray AP01.1 spare parts

Spare parts for ppplication pump OptiSpray AP01.1 AP01




  • Item NO.:

    Gema 1014060 1017438 1010354
  • Payment:

    Paypal, T/T, Western Union
  • Lead Time:

    5-7 days by UPS DHL TNT FEDEX
  • Goods Stock:

    5
  • Product weight:

    6000
  • Warranty:

    1 year
  • Package:

    Strong carton for international express
  • Type:

    Original
  • Quality:

    Completely compatible with original powder coating gun and equipment

Application pump OptiSpray AP01.1 spare parts

gema ap01.1



gema 1014060

gema 1017438

gema 1010354

OptiSpray AP01.1 Application pump

OptiSpray AP01.1 Application pump – complete (pos. 1-14, 24, 27)  1015 447
1  Allen cylinder screw – M5x130 mm  1010 431
2  Upper end piece  1010 428
3  Filter element – 3 µm, complete  1014 060#
4  Allen cylinder screw – M5x35 mm  1005 185
5  Filter element body  1010 046
6  Pinch valve hose – DN7.5  1017 438#
6.1  Braided sleeve – fit-up aid kit for pos. 6 (not shown)  1005 270
7  Allen cylinder screw – M5x65 mm  244 759
8  Bushing  1010 433
9  Upper pinch valve housing  1010 429
10  Lower pinch valve housing  1010 432
11  Fluid blocking ring  1010 354#
12  O-ring – Ø 26x2 mm  246 549#
13  Valves assembly – complete (without pos. 14)  1010 305
14  Body – complete (for pos. 13)  1015 456
15  Nut with kink protection – M16x1-Ø 12 mm  1005 443
16  Elbow connection  1010 051
17  Allen cylinder screw – M5x20 mm  222 950
18  Allen cylinder screw – M4x12 mm  216 275
19  O-ring – Ø 10x2 mm  243 000#
20  Plug  1010 052
21  O-ring – Ø 16x2 mm  1007 794#
22  Suction tube  1010 053
23  O-ring – Ø 6x1 mm  217 115#
24  Connection/plug  200 859
25  Screw-in nipple – 1/8"-Ø 8 mm  1010 378
26  Hose connection – Ø 11.5/7 mm  1019 542
27  O-ring – Ø 7x1.5 mm  1013 549#
30  Powder hose suction side – Ø 4.5 mm (not shown)  1005 454*
31  Powder hose transport side – Ø 11.5/7 mm (not shown)  1005 097*
32  Plastic tube – Ø 8/6 mm, blue  103 497*
33  Plastic tube – Ø 8/6 mm, black  103 152*
34  Plastic tube – Ø 8/6 mm, green  103 519*
40  Hose connection – Ø 8.1/4.5 mm  1010 372
41  O-ring – Ø 8x1.5 mm  248 878#
42  Adaptor  1010 370
43  Nut with kink protection – M12x1-Ø 8 mm  201 316
44  Maintenance set – pos. 3 (2x), 6 (2x), 6.1 (1x), 11 (2x), 12 (4x), 19 (1x), 27 (1x)  1015 435


Bangle Machinery manufactures and supplies non-original replacements and original parts and equipment for Gema, Wagner and Nordson powder coating guns and machines.



Non original parts: they are interchangeable products that completely work well with original powder gun and equipment.

Benefits: powder coating cost will be reduced without lower the powder coating performance. Best option of cost-effective alternative.



Original type: imported from original manufacturers.



For more questions, please contact!
